LWIT-GTW4572
1-Port Modbus Gateway
- Supports 10/100 Mbps communication speeds
- Allows up to 8 clients to access field data simultaneously
- Supports popular HMI software with Modbus/TCP driver or OPC server
- Provides auto-searching device ID Windows utility
- Automatic RS-485 data flow control
- Easy mounting on DIN-rail or panel
- Surge protection for RS-485 and power line
- Supports Modbus/ASCII, RTU Protocol to control devices
LWIT-GTW1211
1-Port Modbus Gateway
- 1 x 10/100 Mbps Ethernet port
- Integrates Modbus TCP and Modbus RTU/ASCII networks
- Baud rate: supports up to 230.4 Kbps
- Supports up to 16 connections per serial port under Modbus client mode and 32 sessions under Modbus server mode
- Built-in 8-kV ESD protection for all serial signals
- Software-selectable RS-232/422/485-2w/485-4w communication
LWIT-GTW1221
1-Port Modbus Gateway
- Security functions refer to the IEC 62443-4-2 standard
- Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
- Integration of Modbus TCP and Modbus RTU/ASCII networks
- Supports up to 921.6 kbps, and any baud rate setting
- Support up to 16 connections on each serial port under Modbus Client mode and 32 sessions under Modbus Server mode.
- Supports agent mode providing the fastest response time.
- Supports Power, Ethernet and Device Redundancy.
- Automatic RS-485 data flow control
- “I” models support a wide operating temperature； “CI” models support isolation and a wide operating temperature
LWIT-GTW1222
2-Port Modbus Gateway
- Security functions refer to the IEC 62443-4-2 standard
- Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
- Integration of Modbus TCP and Modbus RTU/ASCII networks
- Supports up to 921.6 kbps, and any baud rate setting
- Support up to 16 connections on each serial port under Modbus Client mode and 32 sessions under Modbus Server mode.
- Supports agent mode providing the fastest response time
- Supports Power, Ethernet and Device Redundancy
- Software selectable RS-232/422/485 communication
- “I” models support a wide operating temperature ; “CI” models support isolation and a wide operating temperature
