Compact BOX PC

Intel® Core™ Ultra Processors (Series 2), including Ultra 5 225U & Ultra 7 255U (formerly Arrow Lake)
Wide operating temperature: -20 ~ 60 °C; power input: 10 ~ 36 VDC
Up to four display outputs (DP + HDMI + 2 x Type-C)
4 x LAN, 3 x USB 3.2 Gen2, 1 x USB 2.0, 2 x Type-C
4 x RS-232/422/485
2 x M.2 M-key, 1 x M.2 E-key, 1 x M.2 B-key
User-friendly design: side-extractable SIM card, easy RAM & logo replacement, reserved punch-out holes for antennas
Optional DDR5 slots x2, each channel supporting up to 32GB, enabling flexible memory expansion and optimized system performance

LWIT-MEC2372V3

Intel® N250 (1.3GHz, formerly Twin Lake) and Intel Atom® x7433RE (1.5GHz, formerly Amston Lake) quad-core processor
Equipped with one DDR5 memory slot (up to 16GB)
Compact, robust, fanless and scalable system with high stability
Optional second stack for supporting iDoor extension modules, including wireless connectivity, industrial fieldbus and additional I/O ports
1 x M.2 B Key (3042/3052, PCIe x1, USB 3.2/2.0, SATA), 1 x M.2 E key (2230, PCIe x1, USB 2.0) for wireless modules
1 x M.2 M key (2242 NVMe, PCIe x2) for storage
Supports Windows 11 LTSC, Ubuntu 22.04

Intel Atom® x7211RE processor (Dual core) with 8GB LPDDR5 onboard memory and 64 GB eMMC
Pocket-size, robust, fanless and cable-free system with high stability
Optional second stack for increasing functionality including POE, COM, wireless connectivity or iDoor expansion
Support Windows 11 LTSC, Ubuntu 22.04

Intel® Core™ 11th i7/i5/i3 Processor with 8GB DDR4 3200Mb/s memory
4 x GbE, 3 x USB 3.2 Gen2, 1 x USB2.0, 1 x HDMI 1.4, 1 x DP 1.4a, 4 x RS232/422/485
Optional 2nd stack supports up to 2 x iDoor extension for expending wireless connectivity, industrial fieldbus or more I/O
Compact fanless design
Ruggedized by zero cable and lockable I/O design
Supports NVME storage with high data-transmission efficiency

Intel® Celeron® J6412 quad-core processor with 8GB DDR4 memory
Compact, robust, fanless and scalable system with high stability
Optional second stack for supporting extension iDoor module, including wireless connectivity, industrial fieldbus and more I/O ports
Supports NVME storage with high data-transmission efficiency
Supports Windows 11 IoT Enterprise LTSC

Intel® Celeron® Dual core N6210/ Pentium® Quad core N6415 processor with 4GB/8GB DDR4 onboard memory
Pocket-size, robust, fanless and cable-free system with high stability
Optional second stack for increasing functionality including POE, COM, wireless connectivity or iDoor expansion
Support Windows 11 IoT Enterprise LTSC, Win10, Ubuntu Classic and Ubuntu Core 20
Microsoft Azure IoT Edge and Amazon AWS IoT Greengrass certified

Intel® Core™ i7/i5/i3/Celeron Processor with 8GB DDR4 built-in Memory
4 x GbE, 4 x USB 3.0, 1 x HDMI, 1 x DP, 4 x RS232/422/485
Stackable 2nd layer for up to 4 iDoor extension or customize for domain applications
Compact Fanless Design
Ruggedized by zero cable and lockable I/O design
Supports 30+ iDOOR combination with four main categories
Diverse system I/O and Isolated Digital I/O by iDoor Technology
Supports Fieldbus Protocol by iDoor Technology
3G/GPS/GPRS/Wi-Fi Communication by iDoor Technology with RED Compliance

Intel Atom® E3845, Celeron® J1900/J3455 quad-core processor with 4G DDR3L memory
Compact, robust, fanless and cable-free system with high stability
Modular design with optional SSD/ NVME/ Wi-Fi/Bluetooth/cellular scalability
Microsoft Azure IoT Edge and Amazon AWS IoT Greengrass certified

Intel® Atom™ E3815/E3825 processor with 4GB DDR3L onboard memory
2 x GbE, 1 x USB 3.0, 1 x HDMI, Option 2 x RS-232/422/485 or 3 x USB2.0
Compact Fanless Design and Rubber Stopper Design with internal reserved screws for 2nd layer assembly
Diverse system I/O and Isolated Digital I/O by iDoor Technology
Supports Fieldbus Protocol by iDoor Technology
3G/GPS/GPRS/Wi-Fi communication by iDoor technology
Supports 30+ iDoor combination with four main categories of smart factory applications
32GB eMMC storage onboard
RED Compliance for LTE solution

4th Generation Intel® Atom/Celeron J1900 Processor up to 1.91/2.0 GHz with 4GB DDR3L Memory
4/2 x GbE, 3 x USB 2.0 and 1 x USB 3.0/4 x USB 2.0 and 1 x USB 3.0, 2 x RS-232, 2 x RS-422/485 (E3AE), 2 x RS-232/422/485 (J3AE), 1 x VGA, 1 x HDMI, Audio
Compact with Fanless Design
Rubber Stopper Design with Captive Screw
Diverse system IO and Isolated Digital IO by iDoor Technology
Supports MRAM by iDoor Technology
Chassis Grounding Protection
LAN Redundancy (Teaming)
Fault-Protected RS-485 Transceivers With Extended Common-Mode Range
