Products
Automation Controllers
USB-5820
4-ch, 16-bit, 200 kS/s Isolated Analog Output USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built-in USB hub
- 4 x 16-bit analog output channels with 2,500 V DC isolation
- Multiple voltage and current output ranges
- Removable European-type connector
- Supported operating systems: Windows 10/11
USB-5817
8-ch, 16-bit, 200 kS/s Isolated Analog Input USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built-in USB hub
- 8 x 16-bit analog input channels with 2,500 VDC isolation
- Support voltage and current measurement
- Wide common-mode voltage range (±275 V)
- Removable European-type connector
- Supported operating systems: Windows 10/11
USB-5801
4-ch, 24-bit, 192 kS/s USB 3.0 I/O Module for Sound and Vibration (with AO and Tachometer)
- USB 3.0 SuperSpeed and daisy chainable by built-in USB hub
- 4x simultaneously sampled analog inputs, up to 192 kS/s
- 24-bit resolution ADCs with -94 dB total harmonic distortion plus noise (THD+N)
- Built-in anti-aliasing filter
- 2 mA integrated electronic piezoelectric (IEPE) excitation currents
- 2 analog outputs with update rate up to 192 kS/s
- 24-bit resolution DACs with -90 dB total harmonic distortion plus noise (THD+N)
- 2 tachometer inputs for period or frequency measurement
- 4-ch isolated digital input and 4-ch isolated digital output
USB-5830
16-ch Isolated DI and 16-ch Isolated DO USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built in USB hub
- 16-ch digital input and 16-ch digital output with 2,500 VDC isolation
- Wide input voltage range (10 ~ 30 VDC)
- Wide output voltage range (5 ~ 40 VDC) and high output current (350 mA/ch)
- Quick removable European type connector
- LED indicators for I/O status
- Supported operating systems: Windows XP/7/8/10
USB-5860
8-ch Isolated Digital Input and 8-ch Relay USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built in USB hub
- 8-ch Isolated Digital Input and 8-ch Form A-type Relay Output
- Wide input voltage range (10 ~ 30 VDC)
- High-voltage isolation on input channel (2,500 VDC )
- Quick removable European type connector
- LED indicators for I/O status
- Supported operating systems: Windows 10/11
USB-5855
32-ch Isolated Digital Input and 16-ch PhotoMOS Relay USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built in USB hub
- 32-ch digital input and 16-ch PhotoMOS Relay output (Form A) isolation
- Wide input voltage range (10 ~ 30 VDC)
- 1500 VDC optical isolation for relay outputs
- Quick removable European type connector
- LED indicators for I/O status
- Supported operating systems: Windows 10/11
USB-5856
32-ch Isolated DI and 32-ch Isolated DO USB 3.0 I/O Module
- USB 3.0 SuperSpeed
- Daisy chainable by built in USB hub
- 32-ch digital input and 32-ch digital output with 2,500 VDC isolation
- Wide input voltage range (10 ~ 30 VDC)
- Wide output voltage range (5 ~ 40 VDC) and high output current (350 mA/ch)
- Quick removable European type connector
- LED indicators for I/O status
- Supported operating systems: Windows 10/11
USB-4702
10 kS/s, 12-bit, 8-ch Multifunction USB Module
- Supports USB 2.0
- Bus-powered
- 8 x analog input channels
- 12-bit resolution AI
- Sampling rates up to 10 kS/s
- 8-ch DI/8-ch DO, 2-ch AO and one 32-bit counter
- Portable
USB-4704
48 kS/s, 14-bit, 8-ch Multifunction USB Module
- Supports USB 2.0
- Bus-powered
- 8 x analog input channels
- 14-bit resolution AI
- Sampling rate up to 48 kS/s
- 8-ch DI/8-ch DO, 2-ch AO and one 32-bit counter
- Portable
USB-4711A
150 kS/s, 12-bit, 16-ch Multifunction USB Module
- Supports USB 3.0 SuperSpeed
- Bus-powered
- 16 analog input channels
- 12-bit resolution AI
- Sampling rate up to 150 kS/s
- 8-ch DI/8-ch DO, 2-ch AO and one 32-bit counter
- Detachable screw terminal on modules
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
- Portable
USB-4716
200 kS/s, 16-bit, 16-ch Multifunction USB Module
- Supports USB 3.0 SuperSpeed
- Bus-powered
- 16 analog input channels
- 16-bit resolution AI
- Sampling rate up to 200 kS/s
- 8-ch DI/8-ch DO, 2-ch AO and one 32-bit counter
- Detachable screw terminal on modules
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
- Portable
USB-4750
32-ch Isolated Digital I/O USB Module
- Compatible with USB 1.1/2.0
- Bus-powered
- 16 isolated DI and 16 isolated DO channels
- High voltage isolation on all channels (2500 VDC)
- High sink current on isolated output channels (200 mA/Channels)
- Supports 5 ~ 60 VDC isolated input channels
- Interrupt handling capability
- Timer/Counter capability
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
USB-4751
48-ch Digital I/O USB Module
- Compatible with USB 1.1/2.0
- Bus-powered
- 48 TTL digital I/O lines
- Emulates mode 0 of 8255 PPI
- Buffered circuits for higher driving capacity than 8255
- Interrupt handling capability
- Timer/Counter interrupt capability
- Supports both dry and wet contact
- 50-pin Opto-22 compatible box header
- Portable
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
USB-4751L
24-ch Digital I/O USB Module
- Compatible with USB 1.1/2.0
- Bus-powered
- 24 TTL digital I/O lines
- Emulates mode 0 of 8255 PPI
- Buffered circuits for higher driving capacity than 8255
- Interrupt handling capability
- Timer/Counter interrupt capability
- Supports both dry and wet contact
- 50-pin Opto-22 compatible box header
- Portable
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
USB-4761
8-ch Relay and 8-ch Isolated Digital Input USB Module
- Compatible with 1.1/2.0
- Bus-powered
- 8 relay output channels and 8 isolated digital input channels
- LED indicators to show activated relays
- 8 Form C type relay output channels
- High-voltage isolation on input channels (2,500 VDC)
- High ESD protection (2,000 VDC)
- Wide input range (5 ~ 30 VDC)
- Interrupt handling capability
- Portable
- Detachable screw terminal on modules
- Suitable for DIN-rail mounting
- One lockable USB cable for secure connection included
