LWIT-BOX1222
Intel N97 and x7433RE Quad Core SoC with dual HDMI, dual LAN, four COM DIN-Rail Fanless Box PC
- Intel N97 and x7433RE Quad Core SoC
- DIN-Rail system with essential I/O ports on front-side bezel
- Dual independent 4K HDMI
- 2 x Intel i226-IT and 4 x RS-232/422/485
- 2 x USB 3.2 and 2 x USB 2.0
- 8-bit Programmable GPIO
- optional idoor supported
LWIT-BOX1251
Intel® Core Ultra U series processor with three LAN, four COM, HDMI, DP, GbE, GPIO, Remote Switch, USB x 6
- Intel® Core Ultra 5/Ultra 7 Processor
- DDR5-5600 SO-DIMM memory support up 96G
- M.2 E Key, B Key and M Key for storage and wireless module installation
- Up to 3 x Intel GbE, 4 x serial ports, 8-bit DIO, optional CANBus
- Dual displays with 1 x 8K HDMI + 1 x 4K DP
- 2 x USB 3.2 and 4 x USB 2.0
- 12V ~ 28V wide range power input
- -20 ~ 60 °C extended operating temperature
LWIT-BOX1125C
Intel® Atom® Processor x7211E DC SoC with Four Serial Ports, HDMI, GbE, GPIO, Remote Switch, USB x4
- Intel® Atom® Processor x7211E Dual Core SoC
- DDR5-4800 SO-DIMM memory support up 16G
- Four Serial Ports
- M.2 E Key, B Key and M Key for storage and wireless module installation
- TPM for system security by option
- -30 ~ 60 °C extended operating temperature
- 12V lockable DC jack power input
- Advantech DeviceOn support
- IEC 62443-4-2 Certified (Security Level 2), supporting compliance readiness for the EU Cyber Resilience
LWIT-BOX1125H
Intel® Processor N200 QC SoC with Dual HDMI, Dual GbE, Dual Serial Ports, Dual CANBus, Remote Switch, USB x4
- Intel® Processor N-series N200 QC SoC
- DDR5-4800 SO-DIMM memory support up 16G
- Dual HDMI independent display support 4K resolution
- M.2 E Key and B Key for storage and wireless module installation
- TPM for system security by option
- -30 ~ 60 °C extended operating temperature
- 12V lockable DC jack power input
- Advantech DeviceOn support
- RED Certified with selected Wireless Modules
LWIT-BOX1221L
Intel Atom x6413E and Celeron J6412 QC& Celeron N6210 DC SoC with GbE, COM, USB, HDMI/DP and DIO ports DIN-Rail Fanless Box PC
- Intel Atom® x6413E and Celeron® J6412 Quad Core and Celeron® N6210 DC SoC
- DIN-Rail system with essential I/O ports on front-side bezel
- 2 x Intel GbE and 2 x RS-232/422/485
- Dual independent displays with one 4K HDMI and one 4K DP
- 2 x USB 3.2 and 2 x USB 2.0, 1 x internal USB2.0 for security dongle
- 1 x M.2 2280 B key with nano SIM holder and 1 x M.2 2230 E key, 1 x full-size mPCIe
- mSATA and 1 x 2.5″ SATA storage device
- 12V ~ 28V wide range power input, -40 ~ 60 °C and -20 ~ 60 °C extended operating temperature
- No RED Certification
LWIT-BOX1250L
Intel® 11th gen Core™ i processor with Triple LAN/ Quadruple COM Din-Rail Fanless Box PC
- Intel 11th Gen. Core i5/i3
- DIN-Rail system with essential I/O ports on front-side bezel
- 3 x Intel GbE, 4x RS-232/422/485
- 3 x USB 3.2 and 3 x USB 2.0, dual independent displays with one 4K HDMI and one VGA
- 3 Expansion: M.2 E-Key 2230, M.2 B-Key 2280, 1 x Full-size mSATA share with mPCIe slot
- mSATA and 1 x 2.5″ SATA storage device
- 12V ~ 24V wide range power input
- -40 ~ 60 °C extended operating temperature
- WISE-DeviceOn supported for quick AI deployment at scale
LWIT-BOX11
Intel Celeron N3350 DC SoC with 4K Dual HDMI/Dual LAN/M.2 DIN-Rail Fanless Box PC
- Intel Celeron N3350 Dual Core 1.1 GHz
- DIN-Rail system with essential I/O ports on front-side bezel
- 8G DDR3L memory and 128G SSD built-in
- Windows 10 IoT Enterprise built-in
- 60W adaptor bundled in the accessory box
- Dual HDMI display up to 4K resolution
- 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 for WIFI
- 12V ~ 28V wide range power input
- -30 ~ 70 °C extended operating temperature
- Advantech WISE-PaaS/DeviceOn support
LWIT-BOX1220F
Intel Atom E3940 QC SoC with isolated GbE, COM and DIO ports DIN-Rail Fanless Box PC
- Intel Atom® E3940 Quad Core SoC turbo burst up to 1.8 GHz
- DIN-Rail system with essential I/O ports on front-side bezel
- Isolated Intel GbE and COM with protection to 2.5K VDC
- Isolated 8 bit GPIO (4DI/4DO) with with protection to 2.5K VDC
- 12V ~ 28V wide range power input
- Dual independent displays with one 4K HDMI and one VGA
- 1 x full-size mPCIe with nano SIM holder and 1 x M.2 2230 for WIFI
- mSATA and 1 x 2.5″ SATA storage device
- No RED Certification
LWIT-BOX1220L
Intel Atom E3940 QC SoC with 4K Dual HDMI/Dual LAN/M.2 DIN-Rail Fanless Box PC
- Intel Atom E3940 Quad Core SoC turbo burst up to 1.8 GHz
- DIN-Rail system with essential I/O ports on front-side bezel
- 2 x Intel GbE and 4 x USB 3.0
- Dual HDMI display up to 4K resolution
- 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 for WIFI
- 1 x 2.5” SATA III SSD and 1 x full-size mSATA*
- 12V ~ 28V wide range power input
- Advantech WISE-PaaS support
- No RED Certification
LWIT-BOX1124U
Intel Celeron N3350 DC SoC With Dual LAN/ Four USB 3.0/M.2/TPM IoT Gateway Modular Fanless Box PC
- Intel Celeron N3350 Dual Core SoC
- 1 x Full-size miniPCIe with SIM holder for communication module
- 1x M.2 E-key for WIFI module
- -20 ~ 60 °C extended operating temperature
- TPM 2.0 default built-in
- Optional 12~24V power module (Dual Layer)
- Advantech iDoor module compatible (Dual Layer)
- Advantech WISE-DeviceOn support
- FCC and RED for WiFi/BT are available with AMO-WIFI10 in single layer SKU
LWIT-BOX1124H
Intel Atom™ E3940 QC SoC With Dual HDMI/ Dual LAN/ Four USB Modular Fanless Box PC
- Intel Atom E3940 Quad Core SoC
- Dual HDMI independent display support 4k2k resolution
- 1 x M.2 E Key for WIFI module
- TPM built in for well security
- -20 ~ 60 °C extended operating temperature
- Optional 12~24V power module (Dual Layer)
- Advantech iDoor module compatible (Dual Layer)
- Advantech WISE-DeviceOn support
- RED certification for WiFi/BT is available with AMO-WIFI10 in single layer SKU
LWIT-BOX1124C
Intel® Celeron™ N3350 DC SoC With Four Serial Ports Modular Fanless Box PC
- Intel® Celeron™ N3350 Dual Core SoC
- VGA Display, 4 x RS-232/422/485, 2 x USB3.0
- 1 x full-size miniPCIe for communication module
- 1 x 2.5″ SATA III drive bay and 1 x half-size mSATA
- -20 ~ 60 °C extended operating temperature
- 12V lockable DC jack power input
- Optional 12~24V power module (Dual Layer)
- Advantech iDoor module compatible (Dual Layer)
- No RED Certification
LWIT-BOX10
Intel® Celeron Quad Core J1900 Quad Core SoC with Dual GbE and Dual COM Fanless Box PC
- Intel® Celeron J1900 Quad Core 2.0 GHz SoC
- 2G DDR3L Memory & 500G 2.5″ 24×7 SATA HDD Built In
- 2 x GbE for Multiple Internet Transmission
- 2 x RS-232/422/485 (BIOS selection)
- 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module)
- 1 x Half-Size MiniPCIe (ex. mSATA)
- Optional VESA / DIN Rail / Wall Mounting kits
- Threaded DC jack design
- No RED Certification
LWIT-BOX1123L
Intel® Atom E3825 SoC with Dual COM and GPIO Palm-Size Fanless Box PC
- Intel® Atom™ Processor E3825 Dual Core 1.33 GHz SoC
- 1 x 2.5″ SATA HDD/SSD Bay
- 1 x GbE & 1 x VGA & 1 x GPIO
- 1 x RS-232 & 1 x RS-232/422/485
- 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module)
- 1 x Half Size MiniPCIe (ex. mSATA)
- Optional VESA / DIN Rail / Wall Mounting kits
- Threaded DC jack design
- No RED Certification
LWIT-BOX1123C
Intel® Atom E3825 SoC with Dual GbE and Dual COM Fanless Box PC
- Intel® Atom™ E3825 Dual Core 1.33 GHz SoC
- 1 x 2.5″ SATA HDD/SSD Bay & 1 x VGA
- 2 x GbE for Multiple Internet Transmission
- 2 x RS-232/422/485 (BIOS selection)
- 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module)
- 1 x Half-size mSATA
- Optional VESA / DIN Rail / Wall Mounting kits
- Threaded DC jack design
- No RED Certification
LWIT-BOX1123H
Intel® Celeron Quad Core J1900 SoC with Dual HDMI/GbE IoT Fanless BOX PC
- Intel® Celeron J1900 Quad Core 2.0 GHz SoC
- 1 x 2.5″ SATA HDD/SSD Bay
- 2 x GbE for Multiple Internet Transmission
- 2 x Independent HDMI
- 1 x RS-232/422/485 (BIOS selection)
- 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module)
- 1 x Half Size mSATA
- Optional VESA / DIN Rail / Wall Mounting kits
- Threaded DC jack design
- Supports SUSIAccess and Embedded Software APIs
- FCC and RED for WiFi/BT are available with AMO-WIFI08E
LWIT-BOX1551
Intel® 8th Generation Core™ i5/Celeron Slim Fanless Computer
- Gen 8th Intel® Core™ i5/Celeron
- Dual DDR4 2400MHz SO-DIMM memory up to 32G
- 1 x swappable 2.5″ SATA HDD drive bay and 1 x mSATA slot, supports Intel software RAID 0/1
- 4 x USB 3.1 Gen 2, 2 x Intel GbE LAN, 4 x RS-232/422/485, 8 bit GPIO
- 4K2K HDMI and VGA dual independent displays
- 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 E Key
- Support Advantech SQF PCIex2 NVMe storage
- 12V – 24V @ -10%/+20% wide range power input
- RED for WiFi/BT/LTE are available
