Products
Industrial Computing
Panel PCs
Edge AI Systems
LWIT-BOX148V2
Fanless DIN-Rail IPC with Intel® Core™ Processors (13th Gen)
- Intel® Core™ processors (13th Gen) with 8GB DDR5 memory
- Port isolation for 8 x DI, 8 x DO, 4 x COM
- Supports 2 x M.2 M key 2280 NVMe SSD storage (support RAID)
- Supports 1 x M.2 E Key 2230 wi-fi module and 1 x miniPCIe with Nano SIM card slot
- Dual 2500 BASE-T Ethernet supports Time-Sensitive Network (TSN) technology
- Modular design for optional iDoor extension
- Support Windows 11 IoT Enterprise LTSC
LWIT-BOX137V2
Small-Size Integrated DIN-Rail IPC with Intel® Atom® x6413E and x6425RE
- Intel® Atom® x6413E (1.5 GHz) and x6425RE (1.9GHz) processor with 8GB DDR4 memory
- Wide operating temperature range (-40 ~ 70 °C/-40 ~ 158 °F) and wide power input range (10 ~ 36 VDC)
- Port isolation for 8 x DI, 8 x DO, 2 x COM
- DP++ ensures HDMI/DVI compatibility
- Dual storage: 1 xM.2 M-key 2242 PCIe/NVMe or SATA/SSD and 1 x mSATA
- Onboard TPM 2.0 provides hardware-based security
- Modular design for optional iDoor extension
- Ruggedized DIN-rail kit
- Compliant with IEC 61010-1 safety requirements
LWIT-BOX148
UNO-148 Compact DIN-Rail Edge Controller with 11th Gen Intel® Core™ i CPU
- Port isolation for 8 x DI, 8 x DO, 4 x COM
- Supports M.2 M key 2280 NVMe SSD storage, M.2 B key 2242 storage, 3042/3052 cellular modules, and M.2 E Key 2230 wi-fi modules
- Dual 2500BASE-T Ethernet supports Time-Sensitive Network(TSN) technology
- Remote out-of-band (OOB) power management with Advantech iBMC technology
- Microsoft Azure IoT Edge and Amazon AWS IoT Greengrass certified
LWIT-IPC310
Compact Edge Computing Platform with 13th Gen Intel® Core™
- Streamlined size at 180 x 130 x 70 mm
- Seamlessly integrated with the Hailo-8 AI accelerator delivering 26 TOPS
- Dual DDR5 4800MHz memory up to 64GB
- Operates between -20°C and 60°C
- Supports 3 types of monitor connectors: Type-C, DP, HDMI
- Multiple I/O expansion options, including M.2 and adaptive function module
- Supports EdgeGO Device Remote Management Software
LWIT-IPC230
Compact Edge Computing Platform with Intel® N or Atom® X
- Ultra-compact size at 165 x 120 x 62 mm (1.2L)
- 6-12W low-power Intel® CPU
- DDR5 4800MHz memory up to 16GB
- Operates between -20°C to 60°C
- Multiple I/O expansion options, including M.2 and adaptive function module
- Built-in TPM 2.0
- Seamlessly integrated with the Hailo-8 AI accelerator boasting 26 TOPS
- Support In-Band ECC
