Embedded Single Board Computers
-
Intel® Skylake (6th/7th) U-series Processor.Onboard HDMI, LVDS, Display port/VGA, HD Audio,
Serial ATA3, USB3.0 & 2.0, Gigabit LAN,PCIE Mini card, mSATALearn More -
Learn MoreIntel® Braswell Series Processor.
Onboard Display port, HDMI , LVDS,
HD Audio, Serial ATA3,
USB3.0 & 2.0, Gigabit LAN,PCIE Mini card, mSATA -
2 x DDR3L SO-DIMM 1866 up to 8 GB,
onboard HDMI, LVDS, DisplayPort, 4 x Giga LAN,
4 x USB 2.0, 4 x USB 3.0, 2 x RS232/422/485, 4 x RS232,
1 x PS/2, HD Audio, 2 x SATA3, GPIO,
SMBUS, 1 x LPC, 1 x SIM socket,
2 x Mini-PCIe socket (Card1 support mSATA),
1 x SD Card.Learn More -
Intel® Broadwell (5th) / Haswell (4th) Core™
Mobile U-series Processor.Onboard Display port, HDMI , DVI , LVDS,
HD Audio, Serial ATA3, USB3.0 & 2.0, Gigabit LAN,PCIE Mini card, mSATALearn More -
Support Intel® Processor J1900/N2930/E3845 CPU with Onboard Display port, HDMI, CRT,2 x LVDS, HD Audio, Serial ATAII, USB3.0 & 2.0,
Learn More
Gigabit LAN, 2 x PCIE Mini card, mSATA -
Support 3rd and 2nd generation Intel® Core™ i7 / i5 / i3
Mobile CPU with Mobile Intel® QM77 Express,
DDR3 up to 16GB, 6 x Giga LAN,
4 x USB 2.0, 4 x USB 3.0 , 6 x COM, 6 x SATA,
HD Audio,
Mini-PCIe socket, Standard 20-pin ATX P/S or DC 9 ~ 24V input
Learn More -
Learn MoreSupport Intel® Whiskey Lake U Processor.
DDR4 up to 32 GB, onboard HDMI, LVDS,
DisplayPort, 1 x Giga LAN, 1 x Giga PHY LAN,4 x USB 2.0, 4 x USB 3.1, 2 x RS232/422/485,
4 x RS232, 1 x PS/2, HD Audio, 2 x SATA3,GPIO, SMBUS, LPC, PCIe X4,
1 x Mini-PCIe socket (support mSATA), 1 x M.2 (Key E). -
Support 8th & 9th Generation Intel® Core™ Desktop Processor.
DDR4 up to 32 GB, onboard HDMI, LVDS, DVI, VGA, optional DisplayPort, 1 x Giga LAN, 1 x Giga
PHY LAN, 4 x USB 2.0, 6 x USB 3.1,
2 x RS232/422/485, 4 x RS232, 1 x PS/2, HD Audio, 3 x SATA3,GPIO, SMBUS, LPC, PCIe X16,
1 x SIM socket, 1 x Mini-PCIe socket (support mSATA), 1 x Half-SizeMini-PCIe socket.
Learn More -
Support 8th & 9th Generation Intel® Core™ Processor.
DDR4 up to 32 GB, onboard HDMI, LVDS, DVI, VGA, optional DisplayPort, 1 x Giga LAN, 1 x Giga
PHY LAN, 4 x USB 2.0, 6 x USB 3.1, 1 x RS232/422/485,
4 x RS232, 1 x PS/2, HD Audio, 3 x SATA3,2 x GPIO, SMBUS, LPC, PCIe X16, 1 x SIM socket,
2 x Mini-PCIe socket (MINI_CARD2 supportsmSATA).
Learn More -
Learn MoreSupport Apollo Lake Series Processor.
DDR3L up to 8 GB, Onboard HDMI, LVDS, optional DisplayPort or DVI, 2 x Giga LAN, 4 x USB 2.0,
4 x USB 3.0, 2 x RS232/422/485, 4 x RS232,
1 x PS/2, HD Audio, 2 x SATA3, GPIO, SMBUS, 1 x LPC,1 x SIM socket, 1 x Mini-PCIe socket (support mSATA), 1 x Mini PCI, 1 x PCI.
