Industrial MotherBoards
-
- Segments: 1
- Slots: 14 ISA, 4 PCI, 2 PICMG
- Size: 417 x 260 mm (16.42" x 10.24")
- Ordering Information: PCA-6120P4-0B2E
-
- 12-slot backplane for 14-slot half-sized chassis
- Segments:1
- One CPU card slot
- PCIe slot: One x16, Two x1
- PCI slot: Eight 32 bit/33MHz
- Size: 315 x 185 mm
- Compactible with IPC chassis: ACP-4020
- Ordering information: PCE-3B12-08A1E
-
- 13-slot backplane for 14-slot half-sized chassis
- Segments:1
- One CPU card slot
- PCIe slot: Two x8, Two x1
- PCI slot: Eight 32 bit/33MHz
- Size: 315 x 185 mm
- Compactible with IPC chassis: ACP-4020
-
- 6 slot backplane for 6-slot chassis
- Segments:1
- One CPU card slot
- PCIe slot: One x16, Two x1
- PCI slot: Two 32/33
- Size: 142 x 176 mm
- Compactable with IPC chassis: IPC-6806S, IPC-3026
-
- 12-slot backplane for 14-slot half-sized chassis
- Ordering information: PCE-4B12-03A1E
- Compatible with IPC chassis: ACP-4020
- Size: 315 x 185 mm
- PCI slot: Three 32 bit/33MHz
- PCIe slot: One x8, Four x4, Three x1
- One CPU card slot
- Segments:1
-
- 3-slot Butterfly BP for 1U chassis
- Segments: 1
- One CPU card slot
- PCIe slot: One x16
- PCI-X slot: N/A
- PCI slot: 1
- Compatible with IPC chassis: ACP-1320, ACP-1010
-
- 5-slot Butterfly BP for 2U chassis
- Segment: 1
- One CPU card slot
- PCIe slot: One x16
- PCI-X slot: Three 66/100
- PCI slot: N/A
- Compatible with IPC chassis: ACP-2000 and IPC-602
-
- 6-slot Butterfly BP for 2U chassis
- Segments: 1
- One CPU card slot
- PCIe slot: One x16; Four x1
- PCI-X slot: N/A
- PCI slot: N/A
- Compatible with IPC chassis: ACP-2000EBP and IPC-602EBP
-
- 4-slot BP for 5-slot chassis
- Segments: 1
- One CPU card slot
- PCI-X slot: Two 64/133
- PCIe slot: One x16
- PCI slot: N/A
- Compatible with IPC chassis: IPC-6025
-
- 5-slot BP for 5-slot chassis
- Segments: 1
- One CPU card slot
- PCIe slot: One x16; One x4
- PCI-X slot: N/A
- PCI slot: Two
- Compatible with IPC chassis: IPC-6025
