Embedded Single Board Computers
-
- Intel® Pentium N4200 & Celeron N3350, Atom™E3950, E3940, E3930,DDR3L 1867 MHz, up to 8GB
- Triple display: VGA+LVDS/eDP+HDMI/DP*
- 2 Intel i210 GbE, rich I/O: 4COM, 2 SATA, 2 USB 3.0, SMBus/I2C, GPIO M.2 E Key, full-size mSATA, MIOe
- Supports iManager & Software APIs, WISE-DeviceOn
Learn More
-
AMD® G-Series™ Processor T16R 615 MHz /T40E 1.0GHz
Supports up to 4GB DDR3L SODIMM/1G DDR3L On board memory
Supports 18-bit LVDS and VGA
Supports 3 COM ports, 4 USB 2.0 ports, dual GbE and audio codec
Supports extended temp: -40 ~ 85° C
Expansion: PC/104 and half size mini PCIe
Supports SUSIAccess and Embedded Software APIs
Learn More
-
AMD low power LX800 500 MHz processor
24-bit TFT LCD interface, 18/24-bit (JEIDA format) LVDS display
PC/104-plus Expansion
Supports up to 4 COM ports, 4 USB ports
Supports SUSIAccess and Embedded Software APIs
Learn More
-
Intel® Atom™ E3825/E3845 & Celeron® N2930, DDR3L-1066/1333MHz SODIMM up to 8GB
DirectX11, OpenGL3.2, OpenCL1.1, 3 independent display: VGA+LVDS/HDMI+LVDS/DVI+LVDS/VGA+LVDS
Support PC/104-Plus expansion
Rich I/O: 1 GbE, 3 COM, SATA, 6 USB2.0, SMBus/I2C, GPIO, full-size Mini PCIe/full-size mSATA
Supports SUSIAccess and Embedded Software APIs
Learn More
-
Embedded Intel® Pentium N4200 & Celeron N3350
DDR3L 1866 MHz, up to 8GB
Multi-display: VGA+ LVDS/eDP+ HDMI*/DP*
Multiple I/O supports up to 3 Intel GbE, 6 COM, 2 USB3.0, 6 USB2.0
Expansion slot included 1 Mini PCIe, 1 M.2 E-key, 1 mSATA, PCI-104 and 1 PCI Slot
Supports iManager, WISE-Paas/RMM, Embedded Software APIs
Learn More
-
DM&P Vortex86DX, onboard DDR2 memory up to 512 MB
Display type: VGA, 18/24-bit LVDS, 18/24-bit TTL
Supports Floating Point Unit, total power consumption 4 ~ 6 Watts, supports extended temperature to -40 ~ 85° C
Dual Ethernet: 10/100 Ethernet1 and 10/100 Ethernet2, supports PC/104 (8-bit/16-bit ISA) expansion
Supports SUSIAccess, Embedded Software APIs
Learn More
-
- 7th Gen Intel Core i7/i5/i3 + PCH QM175
- Dual channel DDR4 2400, Max 32GB (ECC optional)
- 1 Intel i210 GbE & 1 Intel i219 GbE support iAMT, rich I/O: 2COM, SATA, USB3.0, SMBus/I2C,16 bit GPIO full-size Mini PCIe or mSATA /M.2 E Key support NVME, 12V Power input
- Full-size Mini PCIe or mSATA /M.2 E Key
- Support NVME (optional)
- Supports iManager, WISE-PaaS/RMM, emb. SW API
Learn More
-
AMD G-Series Dual Core T40E and Single Core T16R processor + A55E, DDR3/DDR3L SODIMM up to 4GB
DirectX11 supported. 48-bit LVDS, VGA, 24-bit TTL
Dual GbE, 4 COM, 2 SATA, mSATA
Expansion: PC/104, Mini PCIe, LPC connector for additional COM ports
iManager, SUSIAccess, Embedded software APIs supported
Learn More
-
- Atom® x6000E series and Intel® Celeron® J and N series with Quad/Dual Cores, TDP 6W/ 10W/ 12W
- Single Channel DDR4-3200 up to 32G
- Support 3 independent displays via LVDS, DP1.4, and HDMI2.0 up to 4K@60Hz
- Dual GbE, 6 USB, 6 UART, TPM2.0
- CE/FCC Class B, Coastline I/O ESD 8KV/15KV Criteria A
- Support Windows 10 LTSC & Ubuntu 20.04 LTS, embedded software APIs, WISE-DeviceOn
Learn More
-
Intel® Atom™ E3825 & Celeron® N2930, DDR3L-1066/1333MHz 2GB/4GB on-board memory
DirectX11, OpenGL3.2, OpenCL1.1, 3 independent display: VGA+LVDS/HDMI+LVDS*/Dual LVDS
Support PCI-104 expansion
2 GbE, rich I/O: 4COM, SATA, USB3.0, SMBus/I2C, GPIO, full-size Mini PCIe,full-size mSATA
Supports iManager, SUSIAccess and Embedded Software APIs
Learn More
