Intel® Atom™ E3825 & Celeron® N2930, 3.5" SBC, 2GB/4GB On-board Memory, VGA, 48-bit LVDS, 2GbE, Mini PCIe, PCI-104, iManager - Additional Information
-
Additional Information
Features Intel® Atom™ E3825 & Celeron® N2930, DDR3L-1066/1333MHz 2GB/4GB on-board memory DirectX11, OpenGL3.2, OpenCL1.1, 3 independent display: VGA+LVDS/ HDMI+LVDS*/Dual LVDS Support PCI-104 expansion 2 GbE, rich I/O: 4COM, SATA, USB3.0, SMBus/I2 C, GPIO, full-size Mini PCIe, full-size mSATA Supports iManager (SUSI 4.0), SUSIAccess and Embedded Software APIs Packing List PCM-9365 SBC 1 Startup Manual 1 Ordering Information PCM-9365E-2GS3A1E Diamensions Dimensions (L x W) 146 x 102 mm (5.7" x 4"), same as 3.5" Weight 0.54kg (1.19lb), weight of total package Height Top Side: 19.5 mm; Bottom Side: 7.8 mm; PCB: 1.6 mm - Reviews
-
