- Description
-
Details
BB-232OPDRI premium industrial RS-232 repeater with 2kV optical isolation on both data ports protects equipment and data from ground loops and surges, plus isolation on power supply circuits for a third degree of protection. Data connected via DB9F/DCE and DB9M/DTE. TB power. - Additional Information
-
Additional Information
Features Extend RS-232 data another 15.2 m • 2000 V 3-way optical isolation • Data rates up to 115.2 kbps • -40 to +80 °C wide operating temperature • DIN rail mount IP30 case • 10 to 48 VDC input power (power supply required, sold separately) • UL C1/D2, UL 508, FCC, CE Packing List BB-DR-20-24 – DIN rail mount power supply, 24VDC, 1.0 A output power BB-EK-CLIP-MPC – Replacement DIN rail clip for enclosure BB-TBKT1 – Replacement Terminal Block - 2-position, 5.08mm, 8A, 30 Ordering Information BB-232OPDRI Diamensions 12.3 x 11.3 x 3.2 cm - Reviews
-
- Data Sheet
-
