Embedded Automation Computers

Grid List

Set Ascending Direction

41-50 of 64

  1. ARM based Edge AI Inference Box Computer
    • NVIDIA® Jetson TX2 Dual-Core NVIDIA Denver2 + Quad-core ARM Cortex-A57
    • NVIDAI® Pascal™ 256 CUDA cores GPU
    • 8GB LPDDR4 and 32GB eMMC NAND Flash onboard
    • 1Gigabit Ethernet ports and 2 PoE port (IEEE 802.3af)
    • TensorRT/cuDNN, VisionWorks/OpenCV AI framework support
    • 4K H.264/H.265 encoder & decoder
    • -20 ~ 60 °C operating temperature/ 19V DC Power supply
    Learn More
  2. Embedded PCs
    • Supports Intel® 7th & 6th Gen Core™ i processor (LGA1151) with Intel H110 chipset
    • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
    • Optional 9~36v wide power DC-in design
    • Thin barebone with multi-IO ports w/ 1 full height PCIe Expansion slot is suitable for variety of application
    • Thin design with 44.2mm in height
    • Lock type DC power jack
    Learn More
  3. Embedded PCs
    • Supports Intel Pentium processor N4200/
    • Two 204-pin SO-DIMM up to 8 GB DDR3L 1866 MHz SDRAM
    • Optional 9~36v wide power DC-in design
    • Thin barebone with multi-IO ports w/ 1 full height PCIe Expansion slot
    • Thin design with 44.2mm in height
    Learn More
  4. Embedded PCs
    • Intel 8th. Gen. Core Processor with Quad/Dual Cores (i7/i5), TDP 15W
    • Semi-Industry Fanless slim systen, Din Rail or Wall mount design
    • HDMI + DP* (Support vai MIO+) dual display
    • 4 GbE, 4 USB3.1, 4 USB 2.0, CAN Bus, M.2 M-Key 2280 supports NVMe, M.2 E-key 2230, M.2 B-key, 1 full size of mini PCIe DC-in 12-24V
    • -20 ~ 60 degree extend temperature operating
    • iManager & SW APIs, WISE-PaaS/DeviceOn
    Learn More
  5. Embedded PCs
    • Intel® Braswell Celeron N3160/N3060, Atom E8000, DDR3L-1600MHz SODIMM up to 8GB
    • Fanless slim system with wall-mount & desk mount removable flange, default support VESA mount & Din-rail mount at bottom side
    • Supports 2 x Intel GbE, 8 x USB, HDMI, VGA, 4 x COM and 1 x Digital IO
    • Built-in 1 x full size mSATA and 1 x full size MiniPCIe w/SIM
    • Supports iManager, WISE-PaaS/RMM and Embedded Software APIs
    Learn More
  6. Embedded PCs
    • Intel® Atom N3350 Dual Core SoC
    • Semi-Industry Fanless slim systen, Din Rail or Wall mount design
    • VGA display, COM port, 2 USB3.0, 1 LAN at Front
    • 1 DIO port, 1 COM port at Side
    • Advantech WISE-PaaS/RMM support
    Learn More
  7. Standmount Embedded Automation Controller,
    • Onboard Intel Celeron 847E 1.1GHz/807UE 1.0GHz/Core i7-2655LE 2.2GHz/ i7-3555LE 2.5GHz processors
    • 2 x RS-232 and 2 x RS-232/422/485 ports with automatic flow control
    • 4 x 10/100/1000Base-T Ethernet
    • DVI-I, DP, HDMI support 2 x independent displays
    • Audio with Mic in, Line in, Line out
    • 6 x USB ports
    • Supports 2 x PCI-104 plug-in card with daughterboard expansion
    • Windows® WES 2009, WES 7 ready solution
    • External accessible CFast slot
    • Onboard system status LED indicators
    • Supports wake on LAN and boot from LAN function
    • Supports Power eSATA
    • Isolation between chassis and power ground
    • IP40 ingress protection
    Learn More
  8. Standmount Embedded Automation Controller
    • Intel® Atom™ E3815/E3825 processor with 4GB DDR3L onboard memory
    • 2 x GbE, 1 x USB 3.0, 1 x HDMI, Option 2 x RS-232/422/485 or 3 x USB2.0
    • Compact Fanless Design
    • Rubber Stopper Design with internal reserved screws for 2nd layer assembly
    • Diverse system I/O and Isolated Digital I/O by iDoor Technology
    • Supports Fieldbus Protocol by iDoor Technology
    • 3G/GPS/GPRS/Wi-Fi communication by iDoor technology
    • Supports 30+ iDoor combination with four main categories of smart factory applications
    • 32GB eMMC storage onboard
    Learn More
  9. Standmount Embedded Automation Controller
    • Intel Atom E3845/Celeron® J1900 Quad-Core Processors with 4G DDR3LMemory
    • Robust and cableless design with high stability
    • 2 x GbE, 4 x USB, 4 x RS-232/422/485, 1 x HDMI, 1 x DP
    • Modular design with flexibility to extend second stack for function enhancement
    • Compact size with fanless Design
    • Rubber stopper design for stand mount and optional kit for DIN-rail mount, and VESA mount
    • Optional 3G/GPS/GPRS/Wi-Fi Communication
    Learn More
  10. Standmount Embedded Automation Controller
    • Intel® Core™ i7/i5/i3 Processor with 8GB DDR4 built-in memory
    • 4 x GbE, 4 x USB 3.0, 1 x HDMI, 1 x DP, 4 x RS232/422/485
    • Stackable 2nd layer for up to 4 iDoor extension or customize for domainapplications
    • Compact fanless design
    • Ruggedized by zero cable and lockable I/O design
    • Dedicated TPM2.0 microcontroller designed for hardware security
    • Diverse system I/O and isolated digital I/O by iDoor technology
    • Supports Fieldbus protocol by iDoor technology
    • 3G/GPS/GPRS/Wi-Fi communication by iDoor technology
    • Supports 30+ iDOOR combination with four main categories
    Learn More
